Product Specifications:：
Optical System
– Light Source: 600W white LED module
– Color Temperature: 7500K (customizable) + 24×3535 auxiliary LED beads
– Lifespan: >30,000 hours
– Lens: Effective output aperture diameter 160 mm
Pan & Tilt
– Pan: 540° (8/16-bit resolution)
– Tilt: 270° (8/16-bit resolution)
– Auto-correction and reset function
Display System
– 1.77-inch LCD display with 4 touch buttons
– Display rotatable 180°, with screen off/lock function
– Chinese/English language switching
Color System
– CMY + CTO: Dual-blade smooth color mixing and correction system
– 1 color wheel: 6 colors + white, half-color effect, bidirectional rotating rainbow effect
Gobo System
– 1 fixed gobo wheel: 8 gobos + open, with gobo抖动 (shake)
– 1 rotating gobo wheel: 7 replaceable插拔式 (interchangeable slot-in) rotating gobos + open, bidirectional rotation, gobo shake, adjustable speed
Zoom System
– Linear electronic focusing and smooth focus
– Zoom range: 4°–48°, driven by smooth and silent linear motor
Effects
– Prism: 3-facet + 4-facet prism, forward/reverse rotation
– Frost: Variable linear frost
– Dynamic effects wheel: Independent bidirectional 360° endless rotation
– Dimmer: 0–100% linear dimming
– Strobe: Up to 25 Hz, supports random strobe, speed adjustable
Protection Rating
– IP66
Control
– 31/40 channel modes
– Standard DMX512 protocol
– Supports RDM protocol
Electrical Specifications
– Power supply: AC 100–240V, 50/60 Hz
– Total power consumption: 800W
Dimensions & Weight
– Product dimensions: 390 x 330 x 758 mm
– Net weight: 27.5 kg
