Product Specifications:：
Voltage: AC100-240V 50/60Hz
Power Consumption: 400W
Main Beam: 60W5 pcs LED6065
Auxiliary Aperture: 1W120 pcs (W:40, CW40, RGB40)
Inner Auxiliary Aperture: 0.3W*90 pcs LED3528 RGB
Main Beam Color: Red, Green, Blue, White
Display Screen: Chinese/English menu, touch-sensitive 4-key display
Focusing System: Overall independent control
Beam Angle: 2.8-31°
Field Angle: 5°-46°
Strobe Frequency: 1-25Hz
Dimmer: Electronic dimming 0–100% linear adjustment, with gamma curve dimming, dimming frequency adjustable from 1.2K to 25K, macro command dimming with smooth, stable, flicker-free linearity, adopts stable constant current driver and power supply, suitable for video recording
Tilt Angle: 220° in vertical direction (16-bit precision scanning). Y-axis uses high-speed silent operation for faster and smoother movement. Auto-reposition after accidental movement. Tilt speed adjustable. Tilt reverse and inversion functions. High-precision positioning using optical magnetic encoder.
Tilt Control: 220° forward/reverse
Control Signals: DMX512, RDM, Master/Slave, Sound Active, or Auto Program
Control Channels: 6 DMX channel modes: 21/34/55/69/94/97CH
Power Connection: Power input & output, max. daisy‑chain: 5 units @230V, 3 units @120V
Signal Connection: DMX512 input/output, 3‑pin, max. 30 units
Supported Network Protocol: Artnet
Mounting Method: Quick horizontal alignment / fast locking in horizontal direction
Operating Temperature: -10°C ~ 45°C
IP Rating: IP65
Net Weight: 14 kg
Product Dimensions: 50*13*40.5 cm
