Product Specifications:：
Input Voltage: AC90-240V 50Hz/60Hz
Total Power: 1000W
Light Source: 50 x RGBW 20W ultra-high-brightness LEDs
Rated Lifespan: 50,000 hours
Colors: Unlimited mixing of red, green, blue, white
LED Control: RGBW combined control
Tilt (Vertical): 220° (16-bit precision scanning)
Y-axis driven by high-speed, silent 60 three-phase thick-core motor for smoother and faster movement; auto-reset after unintended movement; adjustable tilt speed; tilt reversal and inversion functions; high-precision positioning via optical electromagnetic encoder
Electronic Strobe: 0.3 – 25 times/second
Dimming: Electronic dimming, 0–100% linear adjustment, with gamma curve dimming frequency adjustable from 1.2kHz to 25kHz; macro command dimming ensures smooth, stable, flicker-free linearity; adopts constant-current driver and power supply suitable for video recording
Control Modes: 11CH (Standard) – one channel mode; standard DMX512 protocol, RDM protocol
Power Connection: Power input & output; max. daisy‑chain: 2 units @ 230V, 1 unit @ 120V
Signal Connection: DMX512 input & output; supports Artnet network protocol
Display: LCD touch screen, bilingual menu (Chinese/English), sensor fault display, temperature display
Cooling System: High-conductivity aluminum heat sink, intelligent fan control (auto fan speed adjustment based on LED temperature), built-in overheat protection intelligent system, intelligent temperature & noise balancing module
IP Rating: IP65
Packaging: Waterproof & shockproof flight case or carton
